Re: RFR: 8256126: Create implementation for NSAccessibilityImage protocol peer

[Alexander Zuev]

On Fri, 15 Jan 2021 08:29:44 GMT, Pankaj Bansal <pban...@openjdk.org> wrote:

> Create implementation for NSAccessibilityImage protocol peer

> @pankaj-bansal please provide some steps to test that a11y for the image
> works.

I use the simple code snippet like this:

<pre>
import java.awt.*;
import java.net.MalformedURLException;
import java.net.URL;
import javax.swing.*;

public class AccessibleImageTest {
    public static void main(String[] args) throws MalformedURLException {
        new AccessibleImageTest().test();
    }

    public void test() throws MalformedURLException {
        JFrame frame = new JFrame("Test frame");
        frame.setLayout(new BorderLayout());
        ImageIcon imageIcon = new ImageIcon(new
URL("https://www.oracle.com/a/ocom/img/i-code-java-300x352-3854596.png";));
        JLabel label = new JLabel(imageIcon);
        label.getAccessibleContext().setAccessibleDescription("I code Java");
        frame.add(label, BorderLayout.CENTER);
        frame.add(new JButton("Top button"), BorderLayout.NORTH);
        frame.add(new JButton("Bottom button"), BorderLayout.SOUTH);
        frame.setDefaultCloseOperation(WindowConstants.EXIT_ON_CLOSE);
        frame.pack();
        frame.setVisible(true);
    }
}
</pre>

After compiling and running the code you should see frame with two buttons on
top and bottom and image in the middle. Now if you turn on VoiceOver with
`<Command><F5>` the accessibility cursor should be on one of the buttons. By
using `<Control><Option><UpArrow>` and `<Control><Option><DownArrow>`
combinations you should be able to move accessibility cursor between buttons
and the image. If image accessibility implemented correctly the accessibility
cursor should be drawn around the image borders and the VoiceOver should
understand the selected element type and take accessible text of the image into
account, so the narration should sound like "I code Java, image". Of course
that also should work with the local images and icon images.

-------------

PR: https://git.openjdk.java.net/jdk/pull/2096
