juliusshufan opened a new issue #9866: The default weight initialization
strategy makes the VGG network difficult to converge when utilizing examples
under 'example/image-classification'
URL: https://github.com/apache/incubator-mxnet/issues/9866


   ## Description
   On trying to train CiFAR-10 dataset with VGG16, I noticed the initial
learning rate has to be set a very small value to make the training converging.
According the implementation of fit.py under
example/image-classification/common, the Xavier with Gaussian random type is
set as the default weight initializing strategy.

   On a NVIDIA P40 GPU, with **CUDA-9.1** and **openblas**, I executed the
following comparison tests:
   Test 1: Initial LR = 0.01          Xavier with **_Gaussian_** random type
   Test 2: Initial LR = 0.00025    Xavier with **_Gaussian_** random type
   Test 3: Initial LR = 0.01          Xavier with **_uniform_** random type

   The following two figures are corresponding to the comparison of the trends
of training top-1 accuracy and cross-entropy loss. The curves in blue, green,
purple are corresponding to test 1, 2, 3 respectively.


![image](https://user-images.githubusercontent.com/33112206/36579904-aae2350e-18a0-11e8-89aa-fc7e3876c0c3.png)

![image](https://user-images.githubusercontent.com/33112206/36579911-bdbcf1d2-18a0-11e8-8e02-d25a057bc56c.png)

   It can be observed, with same initial LR (0.01), the training with
Xavier-Gaussian will not converge.
   Similar test results can also be observed when the dataset changed to
CiFAR-100. (Retrieved from http://data.mxnet.io/data/cifar100.zip)

   ## Environment info (Required)
   HW: NVIDIA P40
   SW:  MxNet master branch, with CUDA-v9.1, CUDNN v7.1 and openblas 2.1

   What to do:
   1. Download the diagnosis script from https://github.com/juliusshufan/mxnet
   2. Run the three python script correspond to test 1, 2, 3
   (Note: The test script modified from the original train_cifar10.py coming
with MXNET examples)

   ## Build info (Required if built from source)
   Compiler: gcc 4.8.5
   MXNet commit hash: cea8d2f4024a5e5d9d9edf43e42be130f10c7c27

   Build config:
   make -j($nproc) USE_OPENCV=1 USE_CUDA=1 USE_CUDNN=1 USE_BLAS=openblas
USE_CUDA_PATH=/usr/local/cuda-9.1

   ## What have you tried to solve it?
   Using the Xavier with uniform random, but not the Gaussian random.


----------------------------------------------------------------
