+title: mTLS everywhere
+authors:
+ - name: Nicolas Fränkel
+ title: Author
+ url: https://github.com/nfrankel
+ image_url: https://avatars.githubusercontent.com/u/752258
+keywords:
+ - Security
+ - TLS
+ - DevOps
+ - cert-manager
+description: >
+ Security in one's information system has always been among the most critical
Non-Functional Requirements. Transport Secure Layer, aka TLS, formerly SSL, is
among its many pillars. In this post, I'll show how to configure TLS for Apache
APISIX.
+tags: [Ecosystem]
+image:
https://blog.frankel.ch/assets/resources/mtls-everywhere/data-key-gcce68039d_large.jpg
+---
+
+>Security in one's information system has always been among the most critical
Non-Functional Requirements. Transport Secure Layer, _aka_ TLS, formerly SSL,
is among its many pillars. In this post, I'll show how to configure TLS for
[Apache APISIX](https://apisix.apache.org/).
+
+<!--truncate-->
+
+<head>
+ <link rel="canonical" href="https://blog.frankel.ch/mtls-everywhere/"; />
+</head>
+
+## TLS in a few words
+
+[TLS](https://wikipedia.org/wiki/Transport_Layer_Security) offers several
capabilities:
+
+* Server authentication: the client is confident that the server it exchanges
data with is the right one. It avoids sending data, which might be
confidential, to the wrong actor
+* Optional client authentication: the other way around, the server only allows
clients whose identity can be verified
+* Confidentiality: no third party can read the data exchanged between the
client and the server
+* Integrity: no third party can tamper with the data
+
+TLS works through certificates. A certificate is similar to an ID, proving the
certificate's holder identity. Just like an ID, you need to trust who delivered
it. Trust is established through a chain: if I trust Alice, who trusts Bob, who
in turn trusts Charlie, who delivered the certificate, then I trust the latter.
In this scenario, Alice is known as the **root certificate authority**.
+
+TLS authentication is based on public key cryptography. Alice generates a
public key/private key pair and publishes the public key. If one encrypts data
with the public key, only the private key that generated the public key can
decrypt them. The other usage is for one to encrypt data with the private key
and everybody with the public key to decrypt it, thus proving their identity.
+
+Finally, mutual TLS, _aka_ mTLS, is the configuration of two-way TLS: server
authentication to the client, as usual, but also the other way around, client
authentication to the server.
+
+We now have enough understanding of the concepts to get our hands dirty.
+
+## Generating certificates with cert-manager
+
+A couple of root <abbr title="Certificate Authority">CA</abbr> are installed
in browsers by default. That's how we can browse HTTPS websites safely,
trusting that <https://apache.org> is the site they pretend to be. The
infrastructure has no pre-installed certificates, so we must start from scratch.
+
+We need at least one root certificate. In turn, it will generate all other
certificates. While it's possible to do every manually, I'll rely on
[cert-manager](https://cert-manager.io/) in Kubernetes. As its name implies,
cert-manager is a solution to manage certificates.
+
+Installing it with Helm is straightforward:
+
+```bash
+helm repo add jetstack https://charts.jetstack.io #1
+
+helm install \
+ cert-manager jetstack/cert-manager \
+ --namespace cert-manager \ #2
+ --create-namespace \ #2
+ --version v1.11.0 \
+ --set installCRDs=true \
+ --set prometheus.enabled=false #3
+```
+
+1. Add the charts' repository
+2. Install the objects in a dedicated namespace
+3. Don't monitor, in the scope of this post
+
+We can make sure that everything works as expected by looking at the pods:
+
+```bash
+kubectl get pods -n cert-manager
+```
+
+```
+cert-manager-cainjector-7f694c4c58-fc9bk 1/1 Running 2 (2d1h ago) 7d
+cert-manager-cc4b776cf-8p2t8 1/1 Running 1 (2d1h ago) 7d
+cert-manager-webhook-7cd8c769bb-494tl 1/1 Running 1 (2d1h ago) 7d
+```
+
+cert-manager can sign certificates from multiple sources: HashiCorp Vault,
Let's Encrypt, etc. To keep things simple:
+
+* We will generate our dedicated root certificate, _i.e._, `Self-Signed`
+* We won't handle certificates rotation
+
+Let's start with the following:
+
+```yaml
+apiVersion: cert-manager.io/v1
+kind: ClusterIssuer #1
+metadata:
+ name: selfsigned-issuer
+spec:
+ selfSigned: {}
+---
+apiVersion: v1
+kind: Namespace
+metadata:
+ name: tls #2
+---
+apiVersion: cert-manager.io/v1
+kind: Certificate #3
+metadata:
+ name: selfsigned-ca
+ namespace: tls
+spec:
+ isCA: true
+ commonName: selfsigned-ca
+ secretName: root-secret
+ issuerRef:
+ name: selfsigned-issuer
+ kind: ClusterIssuer
+ group: cert-manager.io
+---
+apiVersion: cert-manager.io/v1
+kind: Issuer #4
+metadata:
+ name: ca-issuer
+ namespace: tls
+spec:
+ ca:
+ secretName: root-secret
+```
+
+1. Certificate authority that generates certificates **cluster-wide**
+2. Create a namespace for our demo
+3. Namespaced root certificate using the cluster-wide issuer. Only used to
create a namespaced issuer
+4. Namespaced issuer. Used to create all other certificates in the post
+
+After applying the previous manifest, we should be able to see the single
certificate that we created:
+
+```bash
+kubectl get certificate -n tls
+```
+
+```
+NAME READY SECRET AGE
+selfsigned-ca True root-secret 7s
+```
+
+The certificate infrastructure is ready; let's look at Apache APISIX.
+
+## Quick overview of a sample Apache APISIX architecture
+
+[Apache APISIX](https://apisix.apache.org/) is an API Gateway. By default, it
stores its configuration in [etcd](https://etcd.io/), a distributed key-value
store - the same one used by Kubernetes. Note that in real-world scenarios, we
should set up etcd clustering to improve the resiliency of the solution. For
this post, we will limit ourselves to a single etcd instance. Apache APISIX
offers an admin API via HTTP endpoints. Finally, the gateway forwards calls
from the client to an upstre [...]
+
+
+
+Let's start with the foundational bricks: etcd and Apache APISIX. We need two
certificates: one for etcd, in the server role, and one for Apache APISIX, as
the etcd client.
+
+Let's set up certificates from our namespaced issuer:
+
+```yaml
+apiVersion: cert-manager.io/v1
+kind: Certificate
+metadata:
+ name: etcd-server #1
+ namespace: tls
+spec:
+ secretName: etcd-secret #2
+ isCA: false
+ usages:
+ - client auth #3
+ - server auth #3
+ dnsNames:
+ - etcd #4
+ issuerRef:
+ name: ca-issuer #5
+ kind: Issuer
+---
+apiVersion: cert-manager.io/v1
+kind: Certificate
+metadata:
+ name: apisix-client #6
+ namespace: tls
+spec:
+ secretName: apisix-client-secret
+ isCA: false
+ usages:
+ - client auth
+ emailAddresses:
+ - api...@apache.org #7
+ issuerRef:
+ name: ca-issuer #5
+ kind: Issuer
+```
+
+1. Certificate for etcd
+2. Kubernetes `Secret` name, see below
+3. Usages for this certificate
+4. Kubernetes `Service` name, see below
+5. Reference the previously namespaced issuer created earlier
+6. Certificate for Apache APISIX as a client of etcd
+7. Mandatory attribute for clients
+
+After applying the above manifest, we can list the certificates in the `tls`
namespace:
+
+```bash
+kubectl get certificates -n tls
+```
+
+```
+NAME READY SECRET AGE
+selfsigned-ca True root-secret 8m59s //1
+apisix-client True apisix-client-secret 8m22s //2
+etcd-server True etcd-secret 8m54s //2
+```
+
+1. Previously created certificate
+2. Newly-created certificates signed by `selfsigned-ca`
+
+## cert-manager's Certificates
+
+So far, we have created `Certificate` objects, but we didn't explain what they
are. Indeed, they are simple Kubernetes <abbr title="Custom Resource
Definition">CRD</abbr>s provided by cert-manager. Under the cover, cert-manager
creates a Kubernetes `Secret` from a `Certificate`. It manages the whole
lifecycle, so deleting a `Certificate` deletes the bounded `Secret`. The
`secretName` attribute in the above manifest sets the `Secret` name.
+
+```bash
+kubectl get secrets -n tls
+```
+
+```
+NAME TYPE DATA AGE
+apisix-client-secret kubernetes.io/tls 3 35m
+etcd-secret kubernetes.io/tls 3 35m
+root-secret kubernetes.io/tls 3 35m
+```
+
+Let's look at a `Secret`, _e.g._, `apisix-client-secret`:
+
+```bash
+kubectl describe apisix-client-secret -n tls
+```
+
+```
+Name: apisix-client-secret
+Namespace: tls
+Labels: controller.cert-manager.io/fao=true
+Annotations: cert-manager.io/alt-names:
+ cert-manager.io/certificate-name: apisix-client
+ cert-manager.io/common-name:
+ cert-manager.io/ip-sans:
+ cert-manager.io/issuer-group:
+ cert-manager.io/issuer-kind: Issuer
+ cert-manager.io/issuer-name: ca-issuer
+ cert-manager.io/uri-sans:
+
+Type: kubernetes.io/tls
+
+Data
+====
+ca.crt: 1099 bytes
+tls.crt: 1115 bytes
+tls.key: 1679 bytes
+```
+
+A `Secret` created by a `Certificate` provides three attributes:
+
+* `tls.crt`: The certificate itself
+* `tls.key`: The private key
+* `ca.crt`: The signing certificate in the certificate chain, _i.e._,
`root-secret/tls.crt`
+
+Kubernetes encodes `Secret` content in base 64. To get any of the above in
plain text, one should decode it, _e.g._:
+
+```bash
+kubectl get secret etcd-secret -n tls -o jsonpath='{ .data.tls\.crt }' | base64
+```
+
+```
+-----BEGIN CERTIFICATE-----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+-----END CERTIFICATE-----
+```
+
+## Configuring mTLS between etcd and APISIX
+
+With the certificates available, we can now configure mutual TLS between etcd
and APISIX. Let's start with etcd:
+
+```yaml
+apiVersion: v1
+kind: Pod
+metadata:
+ name: etcd
+ namespace: tls
+ labels:
+ role: config
+spec:
+ containers:
+ - name: etcd
+ image: bitnami/etcd:3.5.7
+ ports:
+ - containerPort: 2379
+ env:
+ - name: ETCD_TRUSTED_CA_FILE #1
+ value: /etc/ssl/private/ca.crt
+ - name: ETCD_CERT_FILE #2
+ value: /etc/ssl/private/tls.crt
+ - name: ETCD_KEY_FILE #3
+ value: /etc/ssl/private/tls.key
+ - name: ETCD_ROOT_PASSWORD
+ value: whatever
+ - name: ETCD_CLIENT_CERT_AUTH #4
+ value: "true"
+ - name: ETCD_LISTEN_CLIENT_URLS
+ value: https://0.0.0.0:2379
+ volumeMounts:
+ - name: ssl
+ mountPath: /etc/ssl/private #5
+ volumes:
+ - name: ssl
+ secret:
+ secretName: etcd-secret #5
+```
+
+1. Set the trusted CA
+2. Set the certificate
+3. Set the private key
+4. Require clients to pass their certificate, hence ensuring mutual
authentication
+5. Mount the previously generated secret in the container for access
+
+Now, it's Apache APISIX's turn:
+
+```yaml
+apiVersion: v1
+kind: ConfigMap #1
+metadata:
+ name: apisix-config
+ namespace: tls
+data:
+ config.yaml: >-
+ apisix:
+ ssl:
+ ssl_trusted_certificate: /etc/ssl/certs/ca.crt #2
+ deployment:
+ etcd:
+ host:
+ - https://etcd:2379
+ tls:
+ cert: /etc/ssl/certs/tls.crt #2
+ key: /etc/ssl/certs/tls.key #2
+ admin:
+ allow_admin:
+ - 0.0.0.0/0
+ https_admin: true #3
+ admin_api_mtls:
+ admin_ssl_cert: /etc/ssl/private/tls.crt #3
+ admin_ssl_cert_key: /etc/ssl/private/tls.key #3
+ admin_ssl_ca_cert: /etc/ssl/private/ca.crt #3
+---
+apiVersion: v1
+kind: Pod
+metadata:
+ name: apisix
+ namespace: tls
+ labels:
+ role: gateway
+spec:
+ containers:
+ - name: apisix
+ image: apache/apisix:3.2.0-debian
+ ports:
+ - containerPort: 9443 #4
+ - containerPort: 9180 #5
+ volumeMounts:
+ - name: config #1
+ mountPath: /usr/local/apisix/conf/config.yaml
+ subPath: config.yaml
+ - name: ssl #6
+ mountPath: /etc/ssl/private
+ - name: etcd-client #7
+ mountPath: /etc/ssl/certs
+ volumes:
+ - name: config
+ configMap:
+ name: apisix-config
+ - name: ssl #6,8
+ secret:
+ secretName: apisix-server-secret
+ - name: etcd-client #7,8
+ secret:
+ secretName: apisix-client-secret
+```
+
+1. Apache APISIX doesn't offer configuration via environment variables. We
need to use a `ConfigMap` that mirrors the regular `config.yaml` file
+2. Configure _client_ authentication for etcd
+3. Configure _server_ authentication for the Admin API
+4. Regular HTTPS port
+5. Admin HTTPS port
+6. Certificates for server authentication
+7. Certificates for client authentication
+8. Two sets of certificates are used, one for server authentication for the
Admin API and regular HTTPS, and one for client authentication for etcd.
+
+At this point, we can apply the above manifests and see the two pods
communicating. When connecting, Apache APISIX sends its `apisix-client`
certificate via HTTPS. Because an authority signs the certificate that etcd
trusts, it allows the connection.
+
+I've omitted the `Service` definition for brevity's sake, but you can check
them in the associated [GitHub repo](https://github.com/ajavageek/tls-apisix).
+
+```
+NAME READY STATUS RESTARTS AGE
+apisix 1/1 Running 0 179m
+etcd 1/1 Running 0 179m
+```
+
+## Client access
+
+Now that we've set up the basic infrastructure, we should test accessing it
with a client. We will use our faithful `curl`, but any client that allows
configuring certificates should work, _e.g_, httpie.
+
+The first step is to create a dedicated certificate-key pair for the client:
+
+```yaml
+apiVersion: cert-manager.io/v1
+kind: Certificate
+metadata:
+ name: curl-client
+ namespace: tls
+spec:
+ secretName: curl-secret
+ isCA: false
+ usages:
+ - client auth
+ emailAddresses:
+ - c...@localhost.dev
+ issuerRef:
+ name: ca-issuer
+ kind: Issuer
+```
+
+`curl` requires a path to the certificate file instead of the content. We can
go around this limitation through the magic of zsh: the `=( ... )` syntax
allows the creation of a temporary file. If you're using another shell, you'll
need to find the equivalent syntax or download the files manually.
+
+Let's query the Admin API for all existing routes. This simple command allows
checking that Apache APISIX is connected to etcd, and it can read its
configuration from there.
+
+```bash
+curl --resolve 'admin:32180:127.0.0.1' https://admin:32180/apisix/admin/routes
\ #1
+ --cert =(kubectl get secret curl-secret -n tls -o jsonpath='{
.data.tls\.crt }' | base64 -d) \ #2
+ --key =(kubectl get secret curl-secret -n tls -o jsonpath='{
.data.tls\.key }' | base64 -d) \ #2
+ --cacert =(kubectl get secret curl-secret -n tls -o jsonpath='{
.data.ca\.crt }' | base64 -d) \ #2
+ -H 'X-API-KEY: edd1c9f034335f136f87ad84b625c8f1'
+```
+
+1. `--resolve` avoids polluting one's `/etc/hosts` file. `curl` will translate
`admin` to `localhost`, but the query is sent to `admin` inside the Kubernetes
cluster, thus using the correct `Service`
+2. Get the required data inside the `Secret`, decode it, and use it as a
temporary file
+
+If everything works, and it should, the result should be the following:
+
+```json
+{"total":0,"list":[]}
+```
+
+No routes are available so far because we have yet to create any.
+
+## TLS with upstreams
+
+Last but not least, we should configure TLS for upstreams. In the following,
I'll use a simple [nginx](https://nginx.org/) instance that responds with
static content. Use it as an illustration for more complex upstreams.
+
+The first step, as always, is to generate a dedicated `Certificate` for the
upstream. I'll skip how to do it as we already created a few. I call it
`upstream-server` and its `Secret`, unimaginatively, `upstream-secret`. We can
now use the latter to secure nginx:
+
+```yaml
+apiVersion: v1
+kind: ConfigMap #1
+metadata:
+ name: nginx-config
+ namespace: tls
+data:
+ nginx.conf: >-
+ events {
+ worker_connections 1024;
+ }
+ http {
+ server {
+ listen 443 ssl;
+ server_name upstream;
+ ssl_certificate /etc/ssl/private/tls.crt; #2
+ ssl_certificate_key /etc/ssl/private/tls.key; #2
+
+ root /www/data;
+ location / {
+ index index.json;
+ }
+ }
+ }
+---
+apiVersion: v1
+kind: Pod
+metadata:
+ name: upstream
+ namespace: tls
+ labels:
+ role: upstream
+spec:
+ containers:
+ - name: upstream
+ image: nginx:1.23-alpine
+ ports:
+ - containerPort: 443
+ volumeMounts:
+ - name: config
+ mountPath: /etc/nginx/nginx.conf #1
+ subPath: nginx.conf
+ - name: content
+ mountPath: /www/data/index.json #3
+ subPath: index.json
+ - name: ssl #2
+ mountPath: /etc/ssl/private
+ volumes:
+ - name: config
+ configMap:
+ name: nginx-config
+ - name: ssl #2
+ secret:
+ secretName: upstream-secret
+ - name: content #3
+ configMap:
+ name: nginx-content
+```
+
+1. nginx doesn't allow configuration via environment variables; we need to use
the `ConfigMap` approach
+2. Use the key-certificate pair created via the `Certificate`
+3. Some static content unimportant in the scope of this post
+
+The next step is to create the route with the help of the Admin API. We
prepared everything in the previous step; now we can use the API:
+
+```bash
+curl --resolve 'admin:32180:127.0.0.1'
https://admin:32180/apisix/admin/routes/1 \
+ --cert =(kubectl get secret curl-secret -n tls -o jsonpath='{
.data.tls\.crt }' | base64 -d) \ #1
+ --key =(kubectl get secret curl-secret -n tls -o jsonpath='{
.data.tls\.key }' | base64 -d) \ #1
+ --cacert =(kubectl get secret curl-secret -n tls -o jsonpath='{
.data.ca\.crt }' | base64 -d) \ #1
+ -H 'X-API-KEY: edd1c9f034335f136f87ad84b625c8f1' -X PUT -i -d "{
+ \"uri\": \"/\",
+ \"upstream\": {
+ \"scheme\": \"https\",
#2
+ \"nodes\": {
+ \"upstream:443\": 1
+ },
+ \"tls\": {
+ \"client_cert\": \"$(kubectl get secret curl-secret -n tls -o
jsonpath='{ .data.tls\.crt }' | base64 -d)\", #3
+ \"client_key\": \"$(kubectl get secret curl-secret -n tls -o
jsonpath='{ .data.tls\.key }' | base64 -d)\" #3
+ }
+ }
+ }"
+```
+
+1. Client auth for Admin API, as above
+2. Use HTTPS for the upstream
+3. Configure key-certificate pair for the route. Apache APISIX stores the data
in etcd and will use them when you call the route. Alternatively, you can keep
the pair as a dedicated object and use the newly-created reference (just like
for upstreams). It depends on how many routes the certificate needs. For more
information, check the [SSL
endpoint](https://apisix.apache.org/docs/apisix/admin-api/#ssl)
+
+Finally, we can check it works as expected:
+
+```bash
+curl --resolve 'upstream:32443:127.0.0.1' https://upstream:32443/ \
+ --cert =(kubectl get secret curl-secret -n tls -o jsonpath='{
.data.tls\.crt }' | base64 -d) \
+ --key =(kubectl get secret curl-secret -n tls -o jsonpath='{
.data.tls\.key }' | base64 -d) \
+ --cacert =(kubectl get secret curl-secret -n tls -o jsonpath='{
.data.ca\.crt }' | base64 -d)
+```
+
+And it does:
+
+```json
+{ "hello": "world" }
+```
+
+## Conclusion
+
+In this post, I've described a working Apache APISIX architecture and
implemented mutual TLS between all the components: etcd and APISIX, client and
APISIX, and finally, client and upstream. I hope it will help you to achieve
the same.
+
+The complete source code for this post can be found on
[GitHub](https//github.com/ajavageek/tls-apisix).
+
+**To go further:**
+
+* [How to Easily Deploy Apache APISIX in
Kubernetes](https://apisix.apache.org/blog/2021/12/15/deploy-apisix-in-kubernetes/)
+* [cert-manager](https://cert-manager.io/)
+* [A Simple CA Setup with Kubernetes Cert
Manager](https://medium.com/geekculture/a-simple-ca-setup-with-kubernetes-cert-manager-bc8ccbd9c2)
+* [Mutual TLS Authentication](https://apisix.apache.org/docs/apisix/mtls/)
