+title: Canary releases with Apache APISIX
+authors:
+ - name: Nicolas Fränkel
+ title: Author
+ url: https://github.com/nfrankel
+ image_url: https://avatars.githubusercontent.com/u/752258
+keywords:
+ - DevOps
+ - Canary releases
+ - Deployment strategies
+description: >
+ In a few words, the idea of canary releases is to deliver a new software
version to only a fraction of the users, analyze the results, and decide
whether to proceed further or not. If results are not aligned with
expectations, roll back; if they are, increase the number of users exposed
until all users benefit from the new version.
+ In this post, I'd like to detail this introduction briefly, explain
different ways to define the fraction, and show how to execute it with Apache
APISIX.
+tags: [Ecosystem]
+image: https://static.apiseven.com/uploads/2023/12/05/OH9weScF_bird-5285011.jpg
+---
+
+>In a few words, the idea of canary releases is to deliver a new software
version to only a fraction of the users, analyze the results, and decide
whether to proceed further or not. If results are not aligned with
expectations, roll back; if they are, increase the number of users exposed
until all users benefit from the new version.
+>
+>In this post, I'd like to detail this introduction briefly, explain different
ways to define the fraction, and show how to execute it with Apache APISIX.
+
+<!--truncate-->
+
+<head>
+ <link rel="canonical"
href="https://blog.frankel.ch/canary-releases-apisix/"; />
+</head>
+
+## Introduction to canary releases
+
+The term "canary" originates from the coal mining industry. When mining, it's
not uncommon to release toxic gases: In a small enclosed space, it can mean
quick death. Worse, the gas may be odorless, so miners would breathe it until
it was too late to leave. Carbon monoxide is quite common in coal mines and is
not detectable by human senses.
+
+For this reason, miners brought canaries with them underground. If the canary
suddenly dropped dead, chances were high that such a gas pocket had been
breached, and it was high time to leave the place.
+
+Years ago, we brought this approach to releasing a new software version. The
analogy goes like this: miners are the Ops team deploying the version, the
canary consists of all tools to measure the impact of the release, and the gas
is a (critical) bug.
+
+The most crucial part is that **you need to measure the impact** of the
release, including failure rates, HTTP status codes, etc., and compare them
with those of the previous version. It's outside the scope of this post, but
again, it's critical if you want to benefit from canary releases. The second
most important part is the ability to roll back fast if the new version is
buggy.
+
+## Canary releases vs. feature flags
+
+Note that canary releases are not the only way to manage the risk of releasing
new code. For example, feature flags are another popular way:
+
+* The canary approach delivers the complete set of features in the new
component version
+* Feature flags deploy the component as well, but dedicated configuration
parameters allow activating and deactivating each feature individually
+
+Feature flags represent a more agile approach (in the true sense of the word)
toward rollbacks. If one feature out of 10 is buggy, you don't need to undeploy
the new version; you only deactivate the buggy feature. However, this
superpower comes at the cost of additional codebase complexity, regardless of
whether you rely on third-party products or implement it yourself.
+
+On the other hand, canary requires a mature deployment pipeline to be able to
deploy and undeploy at will.
+
+## Approaches to canary releases
+
+The idea behind canary releases is to allow only a fraction of users to access
the new version. Most canary definitions only define "fraction" as a percentage
of users. However, there's more to it.
+
+The first step may be to allow only vetted users to check that the deployment
in the production environment works as expected. In this case, you may forward
only a specific set of internal users, _e.g._, testers, to the new version. If
you know the people in advance, and the system authenticates users, you can
configure it by identity; if not, you need to fallback to some generic way,
_e.g._, HTTP headers - `X-Canary: Let-Me-Go-To-v2`.
+
+Remember that we must monitor the old and the new systems to look at
discrepancies. If nothing shows up, it's an excellent time to increase the pool
of users forwarded to the new version. I assume you eat your own dog food,
_i.e._; team members use the software they're developing. If you don't, for
example, an e-commerce site for luxury cars, you're welcome to skip this
section.
+
+To enlarge the fraction of users while limiting the risks, we can now
indiscriminately provide the new version to internal users. We can configure
the system to forward to the new version based on the client IP to do this. At
a time when people were working on-site, it was easy as their IPs were in a
specific range. Remote doesn't change much since users probably access the
company's network via a VPN.
+
+Again, monitor and compare at this point.
+
+## The whole nine yards
+
+At this point, everything should work as expected for internal users, either a
few or all. But just as no plan survives contact with the enemy, no usage can
mimic the whole diversity of a production workload. In short, we need to let
regular users access the new version, but in a controlled way, just as we
gradually increased the number of users so far: start with a small fraction,
monitor it, and if everything is fine, increase the fraction.
+
+Here's how to do it with Apache APISIX. Apache APISIX offers a plugin-based
architecture and provides a plugin that caters to our needs, namely the
`traffic-split` plugin.
+
+>The `traffic-split` Plugin can be used to dynamically direct portions of
traffic to various Upstream services.
+>
+>This is done by configuring `match`, which are custom rules for splitting
traffic, and `weighted_upstreams` which is a set of Upstreams to direct traffic
to.
+>
+>--
[traffic-split](https://apisix.apache.org/docs/apisix/plugins/traffic-split/)
+
+Let's start with some basic upstreams, one for each version:
+
+```yaml
+upstreams:
+ - id: v1
+ nodes:
+ "v1:8080": 1
+ - id: v2
+ nodes:
+ "v2:8080": 1
+```
+
+We can use the `traffic-split` plugin to forward most of the traffic to v1 and
a fraction to v2:
+
+```yaml
+routes:
+ - id: 1
+ uri: "*" #1
+ upstream_id: v1
+ plugins:
+ traffic-split:
+ rules:
+ - weighted_upstreams: #2
+ - upstream_id: v2 #3
+ weight: 1 #3
+ - weight: 99 #3
+```
+
+1. Define a catch-all route
+2. Configure how to split traffic; here, weights
+3. Forward 99% of the traffic to v1 and 1% to v1. Note that the weights are
relative to each other. To achieve 50/50, you can set weights 1 and 1, 3 and 3,
50 and 50, etc.
+
+Again, we monitor everything and make sure results are as expected. Then, we
can increase the fraction of the traffic forwarded to v2, _e.g._:
+
+```yaml
+routes:
+ - id: 1
+ uri: "*"
+ upstream_id: v1
+ plugins:
+ traffic-split:
+ rules:
+ - weighted_upstreams:
+ - upstream_id: v2
+ weight: 5 #1
+ - weight: 95 #1
+```
+
+1. Increase the traffic to v2 to 5%
+
+Note that Apache APISIX reloads changes to the file above every second. Hence,
you split traffic in near-real time. Alternatively, you can use the Admin API
to achieve the same.
+
+## More controlled releases
+
+In the above, I moved from internal users to a fraction of external users.
Perhaps releasing to every internal user is too big a risk in your
organization, and you need even more control. Note that you can further
configure the `traffic-split` plugin in this case.
+
+```yaml
+routes:
+ - id: 1
+ uri: /*
+ upstream_id: v1
+ plugins:
+ traffic-split:
+ rules:
+ - match:
+ - vars: [["http_X-Canary","~=","Let-Me-Go-To-v2"]] #1
+ - weighted_upstreams:
+ - upstream_id: v2
+ weight: 5
+ - weight: 95
+```
+
+1. Only split traffic if the `X-Canary` HTTP header has the configured value.
+
+The following command always forwards to v1:
+
+```bash
+curl http://localhost:9080
+```
+
+The following command also always forwards to v1:
+
+```bash
+curl -H 'X-Canary: Let-Me-Go-To-v1' http://localhost:9080
+```
+
+The following command splits the traffic according to the configured weights,
_i.e._, 95/5:
+
+```bash
+curl -H 'X-Canary: Let-Me-Go-To-v2' http://localhost:9080
+```
+
+## Conclusion
+
+This post explained canary releases and how you can configure one via Apache
APISIX. You can start with several routes with different priorities and move on
to the `traffic-split` plugin. The latter can even be configured further to
allow more complex use cases.
+
+The complete source code for this post can be found on
[GitHub](https://github.com/ajavageek/canary-release).
+
+**To go further:**
+
+* [CanaryRelease on Martin Fowler's
bliki](https://martinfowler.com/bliki/CanaryRelease.html)
+* [traffic-split](https://apisix.apache.org/docs/apisix/plugins/traffic-split/)
+* [Implementation of canary release solution based on Apache
APISIX](https://apisix.apache.org/blog/2022/06/14/how-mse-supports-canary-release-with-apache-apisix/)
+* [Canary Release in Kubernetes With Apache APISIX
Ingress](https://navendu.me/posts/canary-in-kubernetes/)
+* [Smooth Canary Release Using APISIX Ingress Controller with
Flagger](https://api7.ai/blog/apisix-ingress-and-flagger-smooth-canary-release)
+* [Apache APISIX Canary
Deployments](https://fluxcd.io/flagger/tutorials/apisix-progressive-delivery/)
