+title: Apache APISIX plugin priority, a leaky abstraction?
+authors:
+ - name: Nicolas Fränkel
+ title: Author
+ url: https://github.com/nfrankel
+ image_url: https://avatars.githubusercontent.com/u/752258
+keywords:
+ - DevOps
+ - plugins
+ - priority
+ - abstraction
+description: >
+ Apache APISIX builds upon the OpenResty reverse-proxy to offer a
plugin-based architecture. The main benefit of such an architecture is that it
brings structure to the configuration of routes. It's a help at scale, when
managing hundreds or thousands of routes.
+ In this post, I'd like to describe how plugins, priority, and phases play
together and what pitfalls you must be aware of.
+tags: [Ecosystem]
+image:
https://static.apiseven.com/uploads/2023/12/09/acT4tzVw_puzzle-3486885.jpg
+---
+
+>[Apache APISIX](https://apisix.apache.org/) builds upon the
[OpenResty](https://openresty.org/en/) reverse-proxy to offer a plugin-based
architecture. The main benefit of such an architecture is that it brings
structure to the configuration of routes. It's a help at scale, when managing
hundreds or thousands of routes.
+>
+>In this post, I'd like to describe how plugins, priority, and phases play
together and what pitfalls you must be aware of.
+
+<!--truncate-->
+
+<head>
+ <link rel="canonical"
href="https://blog.frankel.ch/apisix-plugins-priority-leaky-abstraction/"; />
+</head>
+
+## APISIX plugin's priority
+
+When you configure a route with multiple plugins, Apache APISIX needs to
execute them in a **consistent** order so that the results are the same over
time. For this reason, every APISIX plugin has a _harcoded_ **priority**. You
can check a plugin priority directly in the code. For example, here's the
relevant code fragment for the `basic-auth` plugin:
+
+```lua
+local _M = {
+ version = 0.1,
+ priority = 2520, #1
+ type = 'auth',
+ name = plugin_name,
+ schema = schema,
+ consumer_schema = consumer_schema
+}
+```
+
+1. Priority is 2520
+
+For documentation purposes, the `default-config.yaml` file lists the priority
of all out-of-the-box plugins. Here's an excerpt:
+
+```yaml
+plugins:
+ - ldap-auth # priority: 2540
+ - hmac-auth # priority: 2530
+ - basic-auth # priority: 2520
+ - jwt-auth # priority: 2510
+ - key-auth # priority: 2500
+ - consumer-restriction # priority: 2400
+ - forward-auth # priority: 2002
+ - opa # priority: 2001
+ - authz-keycloak # priority: 2000
+ #- error-log-logger # priority: 1091
+ - proxy-cache # priority: 1085
+ - body-transformer # priority: 1080
+ - proxy-mirror # priority: 1010
+ - proxy-rewrite # priority: 1008
+ - workflow # priority: 1006
+ - api-breaker # priority: 1005
+ - limit-conn # priority: 1003
+ - limit-count # priority: 1002
+ - limit-req # priority: 1001
+```
+
+Imagine a route configured with `proxy-mirror` and `proxy-rewrite`. Because of
their respective priority, `proxy-mirror` would run before `proxy-rewrite`.
+
+```yaml
+upstream:
+ - id: 1
+ nodes:
+ "oldapi:8081": 1
+
+routes:
+ - id: 1
+ uri: "/v1/hello*"
+ upstream_id: 1
+ plugins:
+ proxy-rewrite: #1-3
+ regex_uri: ["/v1(.*)", "$1"]
+ proxy-mirror: #2
+ host: http://new.api:8082
+```
+
+1. The plugin ordering in this file is not relevant
+2. `proxy-mirror` has priority 1010 and will execute first
+3. `proxy-rewrite` has priority 1008 and will run second
+
+The above setup has an issue. For example, if we call
`localhost:9080/v1/hello`, APISIX will first mirror the request, then remove
the `/v1` prefix. Hence, the new API receives `/v1/hello` instead of `/hello`.
It's possible to override the default priority to fix it:
+
+```yaml
+routes:
+ - id: 1
+ uri: "/v1/hello*"
+ upstream_id: 1
+ plugins:
+ proxy-rewrite:
+ _meta:
+ priority: 1020 #1
+ regex_uri: ["/v1(.*)", "$1"]
+ proxy-mirror:
+ host: http://new.api:8082
+```
+
+1. Override the default priority
+
+Now, `proxy-rewrite` has higher priority than `proxy-mirror`: the former runs
before the latter.
+
+In this case, it works flawlessly; in others, it might not. Let's dive further.
+
+## APISIX phases
+
+APISIX runs plugins not only according to their priorities but also through
dedicated phases. Because APISIX builds upon OpenResty, which builds upon
ngxinx, the phases are very similar to the phases of these two components.
+
+nginx defines several
[phases](http://nginx.org/en/docs/dev/development_guide.html#http_phases) an
HTTP request goes through:
+
+1. `NGX_HTTP_POST_READ_PHASE`
+2. `NGX_HTTP_SERVER_REWRITE_PHASE`
+3. `NGX_HTTP_FIND_CONFIG_PHASE`
+4. `NGX_HTTP_REWRITE_PHASE`
+5. `NGX_HTTP_POST_REWRITE_PHASE`
+6. `NGX_HTTP_PREACCESS_PHASE`
+7. `NGX_HTTP_ACCESS_PHASE`
+8. `NGX_HTTP_POST_ACCESS_PHASE`
+9. `NGX_HTTP_PRECONTENT_PHASE`
+10. `NGX_HTTP_CONTENT_PHASE`
+11. `NGX_HTTP_LOG_PHASE`
+
+Each phase focuses on a task, _i.e._, `NGX_HTTP_ACCESS_PHASE` verifies that
the client is authorized to make the request.
+
+In turn, OpenResty offers similarly named phases.
+
+[From nginx
documentation:](https://openresty-reference.readthedocs.io/en/latest/Directives/)
+
+
+
+image:77d1c09e-1a37-11e6-97ef-d9767035fc3e.png[,840,761]
+
+Finally, here are the phases of Apache APISIX:
+
+1. `rewrite`
+2. `access`
+3. `before_proxy`
+4. `header_filter`
+5. `body_filter`
+6. `log`
+
+[From Apache APISIX
documentation:](https://apisix.apache.org/docs/apisix/terminology/plugin/#plugins-execution-lifecycle)
+
+
+
+We have seen two ways to order plugins: by priority and by phase. Now comes
the most important rule: **order by priority only works inside a phase**!
+
+For example, the `redirect` plugin has a priority of 900 and runs in phase
`rewrite`; the `gzip` plugin has a priority of 995 and runs in phase
`body_filter`. Regardless of their respective priorities, `redirect` will
happen before `gzip`, because `rewrite` happens before `body_filter`. Likewise,
changing a priority won't "move" a plugin out of its phase.
+
+The example above with `proxy-mirror` and `proxy-rewrite` worked because both
run in the `rewrite` phase.
+
+The main issue is that priority is documented in the
[config-default.yaml](https://github.com/apache/apisix/blob/master/conf/config-default.yaml#L438)
file, while the phase is buried in the code. Worse, some plugins run across
different phases. For example, let's check the proxy `proxy-rewrite` plugin
and, more precisely, the functions defined
[there](https://github.com/apache/apisix/blob/master/apisix/plugins/proxy-rewrite.lua):
+
+* `local function is_new_headers_conf(headers)`
+* `local function check_set_headers(headers)`
+* `function _M.check_schema(conf)`
+* `function _M.rewrite(conf, ctx)`
+
+The name of the `rewrite()` function is suspiciously similar to one of the
phases above. Looking at other plugins, we see the same pattern repeat. Apache
APISIX runs plugin functions with the same name as the phase.
+
+I took the liberty of summarizing all plugins and their respective phases in a
table.
+
+<table>
+<thead>
+<tr>
+ <th>Plugin</th>
+ <th colspan="6">Phase</th>
+</tr>
+<tr>
+ <th><em>General</em></th>
+ <th><code>rewrite</code></th>
+ <th><code>access</code></th>
+ <th><code>before_proxy</code></th>
+ <th><code>header_filter</code></th>
+ <th><code>body_filter</code></th>
+ <th><code>log</code></th>
+</tr>
+</thead>
+<tbody>
+<tr>
+ <td><code>redirect</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>echo</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>gzip</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>real-ip</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>ext-plugin-pre-req</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>ext-plugin-post-req</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>ext-plugin-post-resp</code></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>workflow</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+</tbody>
+<thead>
+<tr>
+ <th><em>Transformation</em></th>
+ <th><code>rewrite</code></th>
+ <th><code>access</code></th>
+ <th><code>before_proxy</code></th>
+ <th><code>header_filter</code></th>
+ <th><code>body_filter</code></th>
+ <th><code>log</code></th>
+</tr>
+</thead>
+<tbody>
+<tr>
+ <td><code>response-rewrite</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>proxy-rewrite</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>grpc-transcode</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>grpc-web</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>fault-injection</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>mocking</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>degraphql</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>body-transformer</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+ <td></td>
+</tr>
+</tbody>
+<thead>
+<tr>
+ <th><em>Authentication</em></th>
+ <th><code>rewrite</code></th>
+ <th><code>access</code></th>
+ <th><code>before_proxy</code></th>
+ <th><code>header_filter</code></th>
+ <th><code>body_filter</code></th>
+ <th><code>log</code></th>
+</tr>
+</thead>
+<tbody>
+<tr>
+ <td><code>key-auth</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>jwt-auth</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>basic-auth</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>authz-keycloak</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>authz-casdoor</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>wolf-rbac</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>openid-connect</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>cas-auth</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>hmac-auth</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>authz-casbin</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>ldap-auth</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>opa</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>forward-auth</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+</tbody>
+<thead>
+<tr>
+ <th><em>Security</em></th>
+ <th><code>rewrite</code></th>
+ <th><code>access</code></th>
+ <th><code>before_proxy</code></th>
+ <th><code>header_filter</code></th>
+ <th><code>body_filter</code></th>
+ <th><code>log</code></th>
+</tr>
+</thead>
+<tbody>
+<tr>
+ <td><code>cors</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>uri-blocker</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>ua-restriction</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>referer-restriction</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>consumer-restriction</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>csrf</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>public-api</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>chaitin-waf</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+</tbody>
+<thead>
+<tr>
+ <th><em>Traffic</em></th>
+ <th><code>rewrite</code></th>
+ <th><code>access</code></th>
+ <th><code>before_proxy</code></th>
+ <th><code>header_filter</code></th>
+ <th><code>body_filter</code></th>
+ <th><code>log</code></th>
+</tr>
+</thead>
+<tbody>
+<tr>
+ <td><code>limit-req</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>limit-conn</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>limit-count</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>proxy-cache</code> (init)</td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>proxy-cache</code> (disk)</td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>proxy-cache</code> (memory)</td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>request-validation</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>proxy-mirror</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>api-breaker</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>traffic-split</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>request-id</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>proxy-control</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>client-control</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+</tbody>
+<thead>
+<tr>
+ <th><em>Observability</em></th>
+ <th><code>rewrite</code></th>
+ <th><code>access</code></th>
+ <th><code>before_proxy</code></th>
+ <th><code>header_filter</code></th>
+ <th><code>body_filter</code></th>
+ <th><code>log</code></th>
+</tr>
+</thead>
+<tbody>
+<tr>
+ <td><code>zipkin</code></td>
+ <td>X</td>
+ <td>X</td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>skywalking</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>opentelemetry</code></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>prometheus</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>node-status</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>datadog</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>http-logger</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>skywalking-logger</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>tcp-logger</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>kafka-logger</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>rocketmq-logger</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>udp-logger</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>clickhouse-logger</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>syslog</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>log-rotate</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>error-log-logger</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>sls-logger</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>google-cloud-logging</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>splunk-hec-logging</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>file-logger</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>loggly</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>elasticsearch-logger</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>tencent-cloud-cls</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+</tr>
+<tr>
+ <td><code>loki-logger</code></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td>X</td>
+ <td>X</td>
+</tr>
+</tbody>
+<thead>
+<tr>
+ <th><em>Other</em></th>
+ <th><code>rewrite</code></th>
+ <th><code>access</code></th>
+ <th><code>before_proxy</code></th>
+ <th><code>header_filter</code></th>
+ <th><code>body_filter</code></th>
+ <th><code>log</code></th>
+</tr>
+</thead>
+<tbody>
+<tr>
+ <td><code>serverless</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>openwhisk</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>dubbo-proxy</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+<tr>
+ <td><code>kafka-proxy</code></td>
+ <td></td>
+ <td>X</td>
+ <td></td>
+ <td></td>
+ <td></td>
+ <td></td>
+</tr>
+</tbody>
+</table>
+
+## Conclusion
+
+I've detailed Apache APISIX plugin phases and priorities in this post. I've
explained their relationship with one another. Icing on the cake, I documented
each out-of-the-box plugin's phase(s). I hope it will prove helpful.
+
+**To go further:**
+
+* [Default plugin
priorities](https://github.com/apache/apisix/blob/master/conf/config-default.yaml#L438)
+* [Apache APISIX plugin execution
lifecycle](https://apisix.apache.org/docs/apisix/terminology/plugin/#plugins-execution-lifecycle)
+* [Plugin execution
code](https://github.com/apache/apisix/blob/master/apisix/plugin.lua#L1126-L1193)
+
+_Originally published at [A Java
Geek](https://blog.frankel.ch/apisix-plugins-priority-leaky-abstraction/) on
December 10<sup>th</sup>, 2023_
