+title: Implementing the Idempotency-Key specification on Apache APISIX
+authors:
+ - name: Nicolas Fränkel
+ title: Author
+ url: https://github.com/nfrankel
+ image_url: https://avatars.githubusercontent.com/u/752258
+keywords:
+ - APISIX
+ - Idempotency
+ - IETF
+ - specification
+ - plugin
+ - coding
+description: >
+ Last week, I wrote an analysis of the IETF Idempotency-Key specification.
The specification aims to avoid duplicated requests. In short, the idea is for
the client to send a unique key along with the request:
+ If the server doesn't know the key, it proceeds as usual and then stores the
response.
+ If the server knows the key, it short-circuits any further processing and
immediately returns the stored response.
+ This post shows how to implement it with Apache APISIX.
+tags: [Plugin]
+image:
https://static.apiseven.com/uploads/2024/04/09/0rfsRevo_stormtrooper-2899993.jpg
+---
+
+<head>
+ <link rel="canonical"
href="https://blog.frankel.ch/implement-idempotency-key-apisix/"; />
+</head>
+
+>Last week, I wrote an
[analysis](https://apisix.apache.org/blog/2024/04/04/fix-duplicate-api-requests/)
of the [IETF Idempotency-Key
specification](https://datatracker.ietf.org/doc/html/draft-ietf-httpapi-idempotency-key-header-04).
The specification aims to avoid duplicated requests. In short, the idea is for
the client to send a unique key along with the request:
+>
+>* If the server doesn't know the key, it proceeds as usual and then stores
the response
+>* If the server knows the key, it short-circuits any further processing and
immediately returns the stored response
+>
+>This post shows how to implement it with [Apache
APISIX](https://apisix.apache.org/).
+
+<!--truncate-->
+
+## Overview
+
+Before starting coding, we need to define a couple of things. Apache APISIX
offers a plugin-based architecture. Hence, we will code the above logic in a
plugin.
+
+Apache APISIX builds upon OpenResty, which builds upon nginx. Each component
defines phases, which map more or less across the components. For more info on
phases, please see [this previous
post](https://apisix.apache.org/blog/2023/12/14/apisix-plugins-priority-leaky-abstraction/).
+
+Finally, we shall decide on a priority. Priority defines the order in which
APISIX runs plugins _inside a phase_. I decided on `1500`, as all
authentication plugins have a priority in the `2000` and more range, but I want
to return the cached response ASAP.
+
+The specification requires us to store data. APISIX offers many abstractions,
but storage is not one of them. We need access via the idempotency key so it
looks like a key-value store.
+
+I arbitrarily chose Redis, as it's pretty widespread **and** the client is
already part of the APISIX distribution. Note that simple Redis doesn't offer
JSON storage; hence, I use the `redis-stack` Docker image.
+
+The local infrastructure is the following:
+
+```yaml
+services:
+ apisix:
+ image: apache/apisix:3.9.0-debian
+ volumes:
+ - ./apisix/config.yml:/usr/local/apisix/conf/config.yaml:ro
+ - ./apisix/apisix.yml:/usr/local/apisix/conf/apisix.yaml:ro #1
+ - ./plugin/src:/opt/apisix/plugins:ro #2
+ ports:
+ - "9080:9080"
+ redis:
+ image: redis/redis-stack:7.2.0-v9
+ ports:
+ - "8001:8001" #3
+```
+
+1. Static route configuration
+2. Path to our future plugin
+3. Port of Redis Insights (GUI). Not necessary _per se_, but very useful
during development for debugging
+
+The APISIX configuration is the following:
+
+```yaml
+deployment:
+ role: data_plane
+ role_data_plane:
+ config_provider: yaml #1
+
+apisix:
+ extra_lua_path: /opt/?.lua #2
+
+plugins:
+ - idempotency # priority: 1500 #3
+
+plugin_attr: #4
+ idempotency:
+ host: redis #5
+```
+
+1. Configure APISIX for static routes configuration
+2. Configure the location of our plugin
+3. Custom plugins need to be explicitly declared. The priority comment is not
required but is good practice and improves maintainability
+4. Common plugin configuration across all routes
+5. See below
+
+Finally, we declare our single route:
+
+```yaml
+routes:
+ - uri: /*
+ plugins:
+ idempotency: ~ #1
+ upstream:
+ nodes:
+ "httpbin.org:80": 1 #2
+#END #3
+```
+
+1. Declare the plugin that we are going to create
+2. httpbin is a useful upstream as we can try different URIs and methods
+3. Mandatory for static routes configuration!
+
+With this infrastructure in place, we can start the implementation.
+
+## Laying out the plugin
+
+The foundations of an Apache APISIX plugin are pretty basic:
+
+```lua
+local plugin_name = "idempotency"
+
+local _M = {
+ version = 1.0,
+ priority = 1500,
+ schema = {},
+ name = plugin_name,
+}
+
+return _M
+```
+
+The next step is configuration, _e.g._ Redis host and port. For starters, we
shall offer a single Redis configuration across all routes. That's the idea
behind the `plugin_attr` section in the `config.yaml` file: common
configuration. Let's flesh out our plugin:
+
+```lua
+local core = require("apisix.core")
+local plugin = require("apisix.plugin")
+
+local attr_schema = { --1
+ type = "object",
+ properties = {
+ host = {
+ type = "string",
+ description = "Redis host",
+ default = "localhost",
+ },
+ port = {
+ type = "integer",
+ description = "Redis port",
+ default = 6379,
+ },
+ },
+}
+
+function _M.init()
+ local attr = plugin.plugin_attr(plugin_name) or {}
+ local ok, err = core.schema.check(attr_schema, attr) --2
+ if not ok then
+ core.log.error("Failed to check the plugin_attr[", plugin_name, "]",
": ", err)
+ return false, err
+ end
+end
+```
+
+1. Define the shape of the configuration
+2. Check the configuration is valid
+
+Because I defined default values in the plugin, I can override only the `host`
to `redis` to run inside my Docker Compose infrastructure and use the default
port.
+
+Next, I need to create the Redis client. Note that the platform prevents me
from connecting in any phase after the rewrite/access section. Hence, I'll
create it in the `init()` method and keep it until the end.
+
+```lua
+local redis_new = require("resty.redis").new --1
+
+function _M.init()
+
+ -- ...
+
+ redis = redis_new() --2
+ redis:set_timeout(1000)
+ local ok, err = redis:connect(attr.host, attr.port)
+ if not ok then
+ core.log.error("Failed to connect to Redis: ", err)
+ return false, err
+ end
+end
+```
+
+1. Reference the `new` function of the OpenResty Redis module
+2. Call it to get an instance
+
+The Redis client is now available in the `redis` variable throughout the rest
of the plugin execution cycle.
+
+## Implementing the nominal path
+
+In my previous software engineer life, I usually implemented the nominal path
first. Afterward, I made the code more robust by managing error cases
individually. This way, if I had to release at any point, I would still deliver
business values - with warnings. I shall approach this mini-project the same
way.
+
+The pseudo-algorithm on the nominal path looks like the following:
+
+```
+DO extract idempotency key from request
+DO look up value from Redis
+IF value doesn't exist
+ DO set key in Redis with empty value
+ELSE
+ RETURN cached response
+DO forward to upstream
+DO store response in Redis
+RETURN response
+```
+
+We need to map the logic to the phase I mentioned above. Two phases are
available before the upstream, `rewrite` and `access`; three after,
`header_filter`, `body_filter` and `log`. The `access` phase seemed obvious for
work before, but I needed to figure out between the three others. I randomly
chose the `body_filter`, but I'm more than willing to listen to sensible
arguments for other phases.
+
+Note that I removed logs to make the code more readable. Error and
informational logs are necessary to ease debugging production issues.
+
+```lua
+function _M.access(conf, ctx)
+ local idempotency_key = core.request.header(ctx, "Idempotency-Key") --1
+ local redis_key = "idempotency#" .. idempotency_key --2
+ local resp, err = redis:hgetall(redis_key) --3
+ if not resp then
+ return
+ end
+ if next(resp) == nil then --4
+ local resp, err = redis:hset(redis_key, "request", true ) --4
+ if not resp then
+ return
+ end
+ else
+ local data = normalize_hgetall_result(resp) --5
+ local response = core.json.decode(data["response"]) --6
+ local body = response["body"] --7
+ local status_code = response["status"] --7
+ local headers = response["headers"]
+ for k, v in pairs(headers) do --7
+ core.response.set_header(k, v)
+ end
+ return core.response.exit(status_code, body) --8
+ end
+end
+```
+
+1. Extract the idempotency key from the request
+2. Prefix the key so we avoid potential collisions
+3. Get the data set stored in Redis under the idempotency key
+4. If the key is not found, store it with a boolean mark
+5. Transform the data in a Lua table via a custom utility function
+6. The response is stored in JSON format to account for headers
+7. Reconstruct the response
+8. Return the reconstructed response to the client. Note the `return`
statement: APISIX skips the later lifecycle phases
+
+```lua
+function _M.body_filter(conf, ctx)
+ local idempotency_key = core.request.header(ctx, "Idempotency-Key") --1
+ local redis_key = "idempotency#" .. idempotency_key
+ if core.response then
+ local response = { --2
+ status = ngx.status,
+ body = core.response.hold_body_chunk(ctx, true),
+ headers = ngx.resp.get_headers()
+ }
+ local redis_key = "idempotency#" .. redis_key
+ local resp, err = red:set(redis_key, "response",
core.json.encode(response)) --3
+ if not resp then
+ return
+ end
+ end
+end
+```
+
+1. Extract the idempotency key from the request
+2. Arrange the different elements of a response in a Lua table
+3. Store the JSON-encoded response in a Redis set
+
+Tests reveal that it works as expected.
+Try:
+
+```bash
+curl -i -X POST -H 'Idempotency-Key: A'
localhost:9080/response-headers\?freeform=hello
+curl -i -H 'Idempotency-Key: B' localhost:9080/status/250
+curl -i -H 'Idempotency-Key: C' -H 'foo: bar' localhost:9080/status/250
+```
+
+Also, try to reuse a mismatched idempotency key, _e.g._, `A`, for the third
request. As we haven't implemented any error management yet, you'll get the
cached response for another request. It's time to up our game.
+
+## Implementing error paths
+
+The specification defines several error paths:
+
+* Idempotency-Key is missing
+* Idempotency-Key is already used
+* A request is outstanding for this Idempotency-Key
+
+Let's implement them one by one. First, let's check that the request has an
idempotency key. Note that we can configure the plugin on a per-route basis, so
if the route includes the plugin, we can conclude that it's mandatory.
+
+```lua
+function _M.access(conf, ctx)
+ local idempotency_key = core.request.header(ctx, "Idempotency-Key")
+ if not idempotency_key then
+ return core.response.exit(400, "This operation is idempotent and it
requires correct usage of Idempotency Key")
+ end
+ -- ...
+```
+
+Just return the appropriate 400 if the key is missing. That one was easy.
+
+Checking the reuse of an existing key for a different request is slightly more
involved. We first need to store the request, or more precisely, the
fingerprint of what constitutes a request. Two requests are the same if they
have: the same method, the same path, the same body, and the same headers.
Depending on your situation, the domain (and the port) might or may not be part
of them. For my simple implementation, I'll leave it out.
+
+There are several problems to solve. First, I didn't find an existing API to
hash the `core.request` object like there is in other languages I'm more
familiar with, _e.g._, Java's `Object.hash()`. I decided to encode the object
in JSON and hash the string. However, the existing `core.request` has
sub-elements that cannot be converted to JSON. I had to extract the parts
mentioned above and convert the table.
+
+```lua
+local function hash_request(request, ctx)
+ local request = { --1
+ method = core.request.get_method(),
+ uri = ctx.var.request_uri,
+ headers = core.request.headers(),
+ body = core.request.get_body()
+ }
+ local json = core.json.stably_encode(request) --2
+ return ngx.encode_base64(json) --3
+end
+```
+
+1. Create a table with only the relevant parts
+2. The `cjson` library produces JSON whose members might be sorted differently
across several calls. Hence, it results in different hashes. The
`core.json.stably_encode` fixes that issue.
+3. Hash it
+
+Then, instead of storing a boolean when receiving the request, we store the
resulting hash instead.
+
+```lua
+local hash = hash_request(core.request, ctx)
+if next(resp) == nil then
+ core.log.warn("No key found in Redis for Idempotency-Key, set it: ",
redis_key)
+ local resp, err = redis:hset(redis_key, "request", hash)
+ if not resp then
+ core.log.error("Failed to set data in Redis: ", err)
+ return
+ end
+then -- ...
+```
+
+We read the hash stored under the idempotency key on the other branch. If they
don't match, we exit with the relevant error code:
+
+```lua
+local data = normalize_hgetall_result(resp)
+local stored_hash = data["request"]
+if hash ~= stored_hash then
+ return core.response.exit(422, "This operation is idempotent and it
requires correct usage of Idempotency Key. Idempotency Key MUST not be reused
across different payloads of this operation.")
+end
+```
+
+The final error management happens just afterward. Imagine the following
scenario:
+
+1. A request comes with idempotency key X
+2. The plugin fingerprints and stores the hash in Redis
+3. APISIX forwards the request to the upstream
+4. A duplicate request comes with the same idempotency key, X
+5. The plugin reads the data from Redis and finds no cached response
+
+The upstream didn't finish processing the request; hence, the first request
hasn't yet reached the `body_filter` phase.
+
+We append the following code to the above snippet:
+
+```lua
+if not data["response"] then
+ return core.response.exit(409, " request with the same Idempotency-Key for
the same operation is being processed or is outstanding.")
+end
+```
+
+That's it.
+
+## Conclusion
+
+In this post, I showed a simple implementation of the `Idempotency-Key` header
specification on Apache APISIX via a plugin. At this stage, it has room for
improvement: automated tests, the ability to configure Redis on a per route
basis, configure the domain/path to be part of the request, configure a Redis
cluster instead of a single instance, use another K/V store, etc.
+
+Yet, it does implement the specification and has the potential to evolve into
a more production-grade implementation.
+
+The complete source code for this post can be found on
[GitHub](https://github.com/ajavageek/apisix-idempotency-plugin).
+
+**To go further:**
+
+* [Idempotency-Key HTTP Header
Field](https://datatracker.ietf.org/doc/html/draft-ietf-httpapi-idempotency-key-header-04)
+* [Fixing duplicate API
requests](https://apisix.apache.org/blog/2024/04/04/fix-duplicate-api-requests/)
+* [Plugin Develop - APISIX
website](https://apisix.apache.org/docs/apisix/plugin-develop/)
+* [How to Build an Apache APISIX Plugin From 0 to
1?](https://api7.ai/blog/how-to-build-an-apache-apisix-plugin-from-0-to-1)
