Hi Kevin, Thanks for taking a look and thanks for your suggestions.
So, SeaBIOS is not designed to detect and run a VGA option rom from a PCIe video card? I was hoping that I could get SeaBIOS to act similar to the vendor BIOS and not have to use a serial based console. Any ideas on SeaBIOS not booting from hard disks or USB storage devices? Thanks! Nick On Thu, May 7, 2015 at 12:17 PM, Kevin O'Connor <[email protected]> wrote: > On Thu, May 07, 2015 at 08:52:17AM -0700, Nick wrote: > > Hi guys, > > > > I just got coreboot with SeaBIOS payload up and running on a previously > > unsupported system. The system is a Sun Ultra 40 M2 which is very similar > > to the NVIDIA l1_2pvv development board (which already has a coreboot > port.) > > > > Coreboot detects the VGA card and outputs the text "found VGA at PCI: > > 43:00.0", however, SeaBIOS does not seem to be able to detect the VGA > card > > and doesn't seem to enumerate that bus. It would appear that the option > rom > > is not being ran. > > It looks like your board has multiple "root" PCI busses (either that > or coreboot is doing something peculiar with pci). To support this, > seabios needs the CBFS file 'etc/extra-pci-roots' to be set - see: > http://www.coreboot.org/SeaBIOS#Other_Configuration_items > > Ideally, one would set this to the number of extra PCI roots (eg, 1 or > 2), but it can also be set to 255 to force a scan of every PCI bus > (which takes a little longer on each boot). > > > Here's a simple diagram showing roughly how devices are connected on the > > board: http://ibin.co/20n6DtSrgZSv > > > > Here's the console output (SeaBIOS log level 8): > > http://pastebin.com/jKu21dTV > > > > SeaBIOS also detects USB mass storage and hard disk drives, but can not > > boot from them. There's a HALT statement and a bunch of errors (also seen > > in the log file.) The boot device was a USB mass storage device with > linux > > installed and boots successfully with the vendor bios. > > I don't see anything wrong in the log - those messages all appear > normal. It's not uncommon for bootloaders to get confused when a > vgabios isn't present, so I'd track that down first. If you can't get > VGA working, consider installing sgabios as described at: > > http://www.coreboot.org/SeaBIOS#Adding_sgabios_support > > -Kevin >
