pg-yang commented on PR #9725:
URL: https://github.com/apache/skywalking/pull/9725#issuecomment-1265635426
> * Is there any real case about no `node`? That seems a bug rather than a
metric.
Not bug , APISIX prometheus doc show the describe such as `route_id of
the matched Route with request. Defaults to an empty string if the Routes don't
match.` .
Currently only 404 in gateway level could produce empty node/route , my
local test data :
```
apisix_bandwidth{type="egress",route="",service="",consumer="",node=""}
364000
apisix_bandwidth{type="egress",route="routes#1",service="1",consumer="",node="172.18.0.3"}
682000
apisix_bandwidth{type="egress",route="routes#3",service="3",consumer="",node=""}
764000
apisix_bandwidth{type="ingress",route="",service="",consumer="",node=""}
192000
apisix_bandwidth{type="ingress",route="routes#1",service="1",consumer="",node="172.18.0.3"}
386000
apisix_bandwidth{type="ingress",route="routes#3",service="3",consumer="",node=""}
192000
# HELP apisix_http_status HTTP status codes per service in APISIX
# TYPE apisix_http_status counter
apisix_http_status{code="404",route="",matched_uri="",matched_host="",service="",consumer="",node=""}
2000
apisix_http_status{code="404",route="routes#1",matched_uri="/service-a/*",matched_host="",service="1",consumer="",node="172.18.0.3"}
2000
apisix_http_status{code="500",route="routes#1",matched_uri="/service-a/*",matched_host="",service="1",consumer="",node="172.18.0.3"}
2000
apisix_http_status{code="503",route="routes#3",matched_uri="/service-c/*",matched_host="",service="3",consumer="",node=""}
2000
```
> You could aggregate all not-null route and node metrics as the global one.
I would aggregate all metrics as global metrics , don't filter any tag .
> Showing the no route as the no route rule metrics
In no rule case, latency should be nano-sec rather than traditional ms. 1ms
is too slow for a request w/o route rule, right?
I would add a new metrics for displaying http status which request couldn't
match any route , name like `HTTP status (route mismatched)` . I think
displaying latency , bandwidth for invalid request is meaningless , `HTTP
status (route mismatched)` is enough to notice user
--
