I think your problem is that the table below is defined to have 1 column but
has two. Try this:
<table frame="box" rules="all">
<caption>FTPPASVaddr</caption>
<col align="center"/>
<col align="center"/>
<thead>
<tr align="center">
<th>Directive</th>
<th>FTPPASVaddr</th>
</tr>
</thead>
<tbody>
<tr>
<td>Description</td>
<td>This directive allows you to specify a different
IP
address to be sent on replies to <code>PASV</code>
requests.
You will find this useful when the Covalent Enterprise
FTP
Server is behind a firewall.</td>
</tr>
......
</tbody>
</table>
In docbook documents I would define tables like this:
<table>
<title>
....
</title>
<tgroup>
<colspec colname="col1" />
<colspec colname="col2" />
<thead>
<row>
<entry colname="col1">
...
</entry>
<entry colname="col2">
...
</entry>
</row>
</thead>
<tbody>
<row>
<entry colname="col1">
...
</entry>
<entry colname="col2">
....
</entry>
</row>
</tbody>
</tgroup>
</table>
For customizing the docbook DTD see:
http://www.docbook.org/tdg/en/html/ch05.html
Bu you have to customize the docbook stylesheets as well if you add an
directivesynopsis element.
Kai
> -----Original Message-----
> From: [EMAIL PROTECTED]
> [mailto:[EMAIL PROTECTED]
> Behalf Of Dan Carwin
> Sent: Thursday, October 19, 2006 1:29 AM
> To: fop-users@xmlgraphics.apache.org
> Subject: RE: How to make "directives" look better? Customizing/defining
> elements and formatting...
>
>
> Thanks again Jay,
>
> I'm not currently using anything custom, just the basic set of
> pre-defined DocBook elements available in the DocBook editor I'm using.
> Because I am just using these basic tags, my doc looks "basic" and not
> polished. When I looked at the Apache docs I saw many element tags in
> use like <directivesynopsis> which are not available to me and I
> wondered where they came from and how I could make use of them to make
> my doc more readable (and convert to PDF better as well.) I have not
> written any custom transforms yet.
>
> Here's what I use to define a directive:
>
> Example of my directive definition using basic elements:
> ========================================================
> <table frame="box" rules="all">
> <caption>FTPPASVaddr</caption>
>
> <col align="center" span="1" />
>
> <thead>
> <tr align="center">
> <th>Directive</th>
>
> <th>FTPPASVaddr</th>
> </tr>
> </thead>
>
> <tbody>
> <tr>
> <th>Description</th>
>
> <td>This directive allows you to specify a different
> IP
> address to be sent on replies to <code>PASV</code>
> requests.
> You will find this useful when the Covalent Enterprise
> FTP
> Server is behind a firewall.</td>
> </tr>
>
> <tr>
> <th>Syntax</th>
>
> <td><code>FTPPASVaddr IP address</code></td>
> </tr>
>
> <tr>
> <th>Example</th>
>
> <td><code>FTPPASVaddr 64.84.21.111</code></td>
> </tr>
>
> <tr>
> <th>Context</th>
>
> <td>Server Config, Virtual Host</td>
> </tr>
>
> <tr>
> <th>Note</th>
>
> <td>This directive is *not* inherited from the global
> configuration file.</td>
> </tr>
> </tbody>
> </table>
>
>
> Here's what an ASF directive definition looks like:
> ===================================================
> <directivesynopsis>
> <name>BS2000Account</name>
> <description>Define the non-privileged account on BS2000
> machines</description>
> <syntax>BS2000Account <var>account</var></syntax>
> <contextlist><context>server config</context></contextlist>
> <modulelist><module>perchild</module><module>prefork</module></modulelis
> t>
> <compatibility>Only available for BS2000 machines</compatibility>
>
> <usage>
> <p>The <directive>BS2000Account</directive> directive is available
> for
> BS2000 hosts only. It must be used to define the account number for
> the non-privileged apache server user (which was configured using
> the
> <directive module="mpm_common">User</directive> directive). This is
> required by the BS2000 POSIX subsystem (to change the underlying
> BS2000
> task environment by performing a sub-LOGON) to prevent CGI scripts
> from accessing resources of the privileged account which started the
> server, usually <code>SYSROOT</code>.</p>
>
> <note><title>Note</title>
> <p>Only one <code>BS2000Account</code> directive can be used.</p>
> </note>
> </usage>
> <seealso><a href="../platform/ebcdic.html">Apache EBCDIC
> port</a></seealso>
> </directivesynopsis>
>
>
> fyi my first link is to an ASF doc page, and my second link is to a
> static jpg.
>
> Thanks,
> Dan
>
>
> -----Original Message-----
> From: Jay Bryant [mailto:[EMAIL PROTECTED]
> Sent: Wednesday, October 18, 2006 4:14 PM
> To: fop-users@xmlgraphics.apache.org
> Subject: Re: How to make "directives" look better? Customizing/defining
> elements and formatting...
>
>
> Hi, Dan,
>
> You don't need to add formatting objects for FOP to handle (and that's a
> bad
> idea anyway). The thing to do is to write a transform that produces the
> necessary formatting objects. It sounds like you did that and are having
>
> trouble adjusting the layout to suit your needs. From what you say, your
>
> string-breaking issue is the heart of the problem.
>
> Try posting a sample of your problem, so that folks on the list can look
> at
> what you're trying to do and make concrete suggestions.
>
> IMHO, it's better to paste small but complete examples into the body of
> the
> message than it is to attach files or links. I don't know how other
> folks
> work, but I generally ignore attachments and links, even though I have
> anti-virus software.
>
> Jay Bryant
> Bryant Communication Services
>
>
>
> ----- Original Message -----
> From: "Dan Carwin" <[EMAIL PROTECTED]>
> To: <fop-users@xmlgraphics.apache.org>
> Sent: Wednesday, October 18, 2006 5:14 PM
> Subject: How to make "directives" look better? Customizing/defining
> elements
> and formatting...
>
>
> This is another newb question, and please forgive me as I fear it is off
> topic for this list.
> (please point me in the right direction)
>
> Quick version:
> ==============
> Where and how do I define new element types? (How) Can I import
> existing ones I like from the ASF?
>
>
> Explanation
> ===========
> I am writing technical documentation and need to document Apache HTTPD
> conf file "directives".
>
> Example:
> http://httpd.apache.org/docs/2.0/mod/mpm_common.html#acceptmutex
>
> In the Apache docs (linked above) there is a really nice format for a
> "directive" which encapsulates the directive in a box and formats the
> header elements of the directive in bold, etc.
>
> I am currently using a "table" to format my directives, and they look
> like crap. :) Especially when converted to PDF, as the first column of
> the table takes up 80% of the page width and the second column is right
> off the page:
>
> Example: http://www.sonic.net/dcarwin/images/directive-example.jpg
>
> Thus the question is how can I make my directive definitions look like
> the ASF's?
>
> Best I can tell I have to define or import new custom elements, such as
> <directivesynopsis> which are used in the ASF docs, which are not
> defined currently in the list of element types I have access to. These
> new element definitions also have to include instructions to FOP on how
> to format them when converted to PDF. (right?)
>
> Environment notes:
> ==================
> I use XML Mind Editor 3.2 to edit the docs.
>
> Here is an example of the command I am using to convert into PDF (direct
> from XML).
>
> "C:\"Program Files"\apacheFOP\fop-0.92beta\fop.bat -xml
> E:\data\covalentDocumentation\new-xml-docs\ERS-3.1.0-Release_Notes.xml
> -xsl E:\data\docbook\docbook-xsl-1.70.1\fo\docbook.xsl -pdf
> E:\data\covalentDocumentation\new-xml-docs\ERS-3.1.0-Release_Notes.xml.p
> df"
>
>
> Thanks,
> Dan Carwin
> [EMAIL PROTECTED]
>
>
> ---------------------------------------------------------------------
